Questions & Answers

Q: QuestionWhat is the purpose of the AccuEQ feature?

• A:Answer AccuEQ is an automatic room acoustic calibration system that optimizes the sound output based on your speaker setup and room dimensions.

Q: QuestionDoes this receiver work with Sonos speakers?

• A:Answer Yes, you can integrate this receiver with your Sonos Home Sound System by pairing it with a Sonos Connect or Port (sold separately).

Q: QuestionWhat is the wattage output per channel for this receiver?

• A:Answer This receiver delivers 100 watts per channel at 8 ohms.

Q: QuestionHow many HDMI inputs does the Onkyo TX-NR6100 have?

• A:Answer This receiver has a total of 6 HDMI inputs.

Q: QuestionCan I stream music wirelessly to this receiver?

• A:Answer Yes, the Onkyo TX-NR6100 supports bi-directional Bluetooth wireless technology for audio streaming.

Q: QuestionDoes this Onkyo receiver support Dolby Atmos?

• A:Answer Yes, the Onkyo TX-NR6100 supports Dolby Atmos and DTS:X for an immersive 3D sound experience.

Q: QuestionDoes this work with two sets of Atmos speakers? One up font and one in back? The manual is very confusing since it shows two sets of an Atmos setup, but no way to actually wire the config in another part of the manual.

Asked 1 year ago by Dman.

• A:Answer No. You can determine this by how many channels it supports. This is 7.2, so 7 speakers and 2 subwoofers. If you are looking to get the standard surround sound (center, front left, front right, rear left, rear right) + the Atmos height channels (front left height, front right height, rear left height, rear right height) you would need 9 speakers. So, this will support 5.2.2 but not 5.4.2. That said, 5.2.2 is very enveloping.

  Answered 1 year ago by csmithVerified Purchase

  Helpful (8)Unhelpful (1)ReportAnswer this question

Q: QuestionI have speakers on my back porch. When watching a game and grilling I want the back porch speakers to play the audio from the game, which is also playing in 5.1 from DirectTV in the main room. My current device will only play analog inputs to the 2nd room

Asked 2 years ago by CraigD.

• A:Answer This was my same experience but with this unit can play anything on zone 2 and best of all, can control it with the Onkyo phone app. So can switch from game to Amazon Music during half-time then back again without leaving the patio or other rooms where i have speakers set up.

  Answered 2 years ago by MarkFVerified Purchase

  Helpful (7)Unhelpful (0)ReportAnswer this question

Q: QuestionHow many watts per channel ?

Asked 3 years ago by Param11.

• A:Answer 100 W/Ch (8 ohms, 20 Hz–20 kHz, 0.08% THD, 2-ch driven, FTC)

  Answered 3 years ago by jel13

  Helpful (16)Unhelpful (0)ReportAnswer this questionShow more answers (2)

Q: QuestionDoes this receiver have Variable Refresh Rate (VRR), Quick Frame Transport (QFT), and Auto Low Latency Mode (ALLM)

Asked 3 years ago by Darrylwoo.

• A:Answer Yes, All of the 2021 Onkyo receivers support VRR, QTF, ALLM.

  Answered 3 years ago by OnkyoSupportTeam

  Helpful (5)Unhelpful (0)ReportAnswer this question

Q: QuestionI see this does 8K at 60hz, but does it do 4K at 120Hz? For Xbox Series X.

Asked 3 years ago by TD374.

• A:Answer Yes. 1-3 hdmi ports only. Settings on receiver - 8K enhanced on what ever 1-3 ports you plugged in your series x. Then change any settings on the series x to get the full 4k 120hz. Also make sure yo have a certified 2.1 cable.

  Answered 3 years ago by jel13

  Helpful (4)Unhelpful (0)ReportAnswer this questionShow more answers (1)

Q: QuestionCan I connect the TX-NR6100 to a laptop through both the HDMI & USB ports to play music from the laptop through the speakers connected to the TX-NR6100 Receiver? Also, can I accomplish the same through Wifi?

Asked 2 years ago by LouisD65.

• A:Answer You can connect through USB port and it works fine, but for HDMI your laptop should have HDMI eARC or ARC (audio return channel) which most laptop computers do not have. The easiest way to connect it is via a network whether wired or wireless is through the dts play-fi app. this receiver supports dts play-fi

  Answered 2 years ago by Aleksandar

  Helpful (3)Unhelpful (0)ReportAnswer this questionShow more answers (1)

Q: QuestionWhat is the total harmonic distortion and the signal to noise ratio?

Asked 2 months ago by Pj.

• A:Answer Hello Pj, Here is the information that you had asked for about the TXNR6100: 8 ohms 100 watts per channel per channel rms 0.08% THD Signal to Noise Ratio: 106 dB (IHF-A, LINE IN, SP OUT), 80 dB (IHF-A, PHONO IN, SP OUT) Thank you Onkyo

  Answered 2 months ago by Onkyo Team

  Helpful (1)Unhelpful (0)ReportAnswer this question

Q: QuestionI have an old Onkyo EQ-35. Is this receiver compatible with that?

Asked 4 months ago by Equalizer.

• A:Answer Hello Equalizer, You can hook up the eq to the TXNR6100, but you would only be able to equalize one device not the whole receiver. The device would have to be connected to the EQ input and then you would connect the output of the EQ to go into the input of the receiver (except Phono). If you had one of the older receivers that had the amp in and pre-out connections, then you would be able to equalize all the devices that were connected to the receiver instead of just one device. Thank you Onkyo

  Answered 4 months ago by Onkyo Team

  Helpful (1)Unhelpful (0)ReportAnswer this question

Q: QuestionFollow up question here. I have the center channel speaker with an impedance of 4 ohms while the rest of my other home theater speakers run at 8 ohms. Will this receiver be able compatible with this type of setup?

Asked 4 months ago by Santino.

• A:Answer Hello Santino, It is not recommended to mix the 4 and 8ohm speakers together. That could cause the unit to go into protection and shut down. However, you can mix the 6 and 8ohm together but the 4 ohm should only be with a 4ohm for all speakers. Then you would set the setting within the receiver's menu for speaker impedance to let it know what speakers that are you using for your configuration. Thank you Onkyo

  Answered 4 months ago by Onkyo Team

  Helpful (1)Unhelpful (0)ReportAnswer this question

Q: QuestionCan I use external amps with this to power a couple of the speaker channels? I've got two old school integrated amps that have pre/power rca jacks but am new to AV tech and can't figure how to run them with this. Thanks

Asked 1 year ago by Birf.

• A:Answer Yes. There is a set of line out jacks that can be used for a zone 2 or Zone B. Zone B will replicate what is playing in the main zone and Zone 2 can play a different source. but might assign the height channels speaker output to the line out jacks so then your main zone would be limited to 5.1.

  Answered 1 year ago by Cat5GuyVerified Purchase

  Helpful (1)Unhelpful (0)ReportAnswer this question

Q: QuestionCan I use Bluetooth headphones with this ?

Asked 1 year ago by Raymond.

• A:Answer Yes you can I haven’t try yet,

  Answered 1 year ago by CassandraBVerified Purchase

  Helpful (1)Unhelpful (0)ReportAnswer this question

Q: QuestionHow do I get all 7 speakers to work in surround sound? Either the front works or the back but never all 7

Asked 1 year ago by Anonymous.

• A:Answer Depending on how you set up your system. I got mine on a 5.2.2 setup. You need to make sure you're on Dolby surround. If the movie or show you're watching has surround sound it will come on. Depending on what your watching, you may not hear anything from the back. If you just want to hear all the sound equally played out of all the speakers, make sure you put it on stereo. That will play all the sound equally through every speaker. Again, it really depends on how you set up your system. Is it a 7.1 for 5.1 or 5.2.2?

  Answered 1 year ago by Gam3rdadVerified Purchase

  Helpful (1)Unhelpful (0)ReportAnswer this question

Q: QuestionCan I power the receiver on and off with my voice?

Asked 2 years ago by RockManX77777.

• A:Answer Your voice is not loud enough no.

  Answered 2 years ago by BIGASSMIKEVerified Purchase

  Helpful (2)Unhelpful (1)ReportAnswer this question

Q: QuestionCan I connect/insert a USB 3.1 drive that is backward compatible to USB 2.0, or must the USB Drive be only USB 2.0?

Asked 2 years ago by Memory.

• A:Answer I had to use one to update the firmware so yes.

  Answered 2 years ago by IsiacVerified Purchase

  Helpful (1)Unhelpful (0)ReportAnswer this question
